Маршрутизатор Teltonika RUTM10 (RUTM10000000)

Доставка со склада 5-10 дней.

Teltonika RUTM10 (RUTM10000000) -это твердый промышленный маршрутизатор, оснащенный 4 -кратным гигабитным портами Ethernet, двумя Wi -Fi 2,4 ГГц и 5 ГГц, эффективным программным обеспечением и программным обеспечением Rutos для передовых сетевых решений. Маршрутизатор обеспечивает высокую скорость передачи данных и просмотр интернета без проблем. RUTM10 имеет все последние функции безопасности и возможность удаленно контролировать и контролировать данные, используемые в офисе.

Teltonika RUTM10-это маршрутизатор, оснащенный четырьмя гигабитными портами RJ45 и вариантами связи Wi-Fi 5, благодаря которому он идеально подходит для приложений, требующих как проводных соединений, так и опций беспроводного доступа в Интернет. RUTM10 может создать сеть Wi-Fi сетей в рамках сетевых решений, обеспечивая более плавное и более надежное использование беспроводной сети, обеспечивая при этом высокий уровень безопасности благодаря работе сети VPN, такой как OpenVPN, IPSec, IPSec, Wireguard и Tailscale.

RUTM10 может работать до 128 VLAN на основе тегов/портов для повышения гибкости сети, а также во многих сетях VPN и протоколах связи M2M, которые особенно важны в промышленных средах. Маршрутизатор имеет расширенную систему Rutos, основанную на OpenWRT, USB -порту, а также поддерживает функцию брандмауэра, VPN и RMS. Это отличное промышленное устройство, в котором мобильное или Wi-Fi-подключение не требуется. Устройство заключено в алюминиевый корпус.

Zawartość zestawu:Router RUTM10Zasilacz 18 W - Teltonika PR3PXEU3 zasilacz 12V 1.5A2x anteny WiFi (obrotowe, RP-SMA męskie) - Teltonika PR14RD35 antena Wi-Fi dual-band RP-SMAKabel ethernet (1.5 m)QSG (skrócona instrukcja obsługi)PudełkoNajważniejsze cechy:4x Gigabitowe porty Ethernet z prędkością do 1000 Mb/sDwuzakresowe Wi-Fi z funkcją Mesh i szybkiego roaminguWiFi 2.4GHz i 5GHz, AC1200Dwurdzeniowy procesor MediaTek, 880 MHz i 256MB pamięci RAM1x port USB 2.0Szeroki zakres napięć zasilania dla łatwiejszej integracji - 9-50VSystem zdalnego zarządzania Teltonika - RMSObsługa wielu protokołów VPN, w tym Tailscale, OpenVPN, IPsec, ZeroTier i inneObsługa do 128 sieci VLAN opartych na tagach/portachObsługa wielu protokołów przemysłowych, w tym MQTT, Modbus, DNP3, DLMSŁatwy w użyciu, bezpieczny i funkcjonalny system operacyjny oparty na OpenWrtWIRELESSWireless mode: 802.11b/g/n/ac Wave 2 (WiFi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO), 802.11r fast transition, Access Point (AP), Station (STA)Wi-Fi security: WPA2-Enterprise - PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, Auto-cipher modes, client separation, EAP-TLS with PKCS#12 certificates, disable auto-reconnectSSID/ESSID: ESSID stealth modeWi-Fi users: Up to 150 simultaneous connectionsWireless Connectivity Features: Wireless mesh (802.11s), fast roaming (802.11r), BSS transition management (802.11v), radio resource measurement (802.11k)Wireless MAC filter: Whitelist, blacklistWireless QR code generator: Once scanned, a user will automatically enter your network without needing to input login information. ETHERNETWAN: 1 x WAN port 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossoverLAN: 3 x LAN ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossoverNETWORKRouting: Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routingNetwork protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL)VoIP passthrough support: H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packetsConnection monitoring: Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspectionFirewall: Port forward, traffic rules, custom rulesFirewall status page: View all your Firewall statistics, rules, and rule countersPorts management: View device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and so onNetwork topology: Visual representation of your network, showing which devices are connected to which other devicesDHCP: Static and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcardsQoS / Smart Queue Management (SQM): Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11eDDNS: Supported >25 service providers, others can be configured manuallyNetwork backup: Wi-Fi WAN, VRRP, Wired options, each of which can be used as an automatic FailoverLoad balancing: Balance Internet traffic over multiple WAN connectionsHotspot: Captive portal (hotspot), internal/external Radius server, Radius MAC authentication, SMS authorisation, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customisable themes and optionality to upload and download customised hotspot themesSSHFS: Possibility to mount remote file system via SSH protocolVRF support: Initial virtual routing and forwarding (VRF) supportSECURITYAuthentication: Pre-shared key, digital certificates, X.509 certificates, TACACS+, Radius, IP & login attempts block, time-based login blocking, built-in random password generatorFirewall: Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-TAttack prevention: DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)VLAN: Port and tag-based VLAN separationWEB filter: Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites onlyAccess control: Flexible access control of SSH, Web interface, CLI and TelnetVPNOpenVPN: Multiple clients and a server can run simultaneously, 27 encryption methodsOpenVPN Encryption: DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128, AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128, AES-128-OFB 128, AES-128-GCM 128, AES-192-CFB 192, AES-192-CFB1 192, AES-192-CFB8 192, AES-192-OFB 192, AES-192-CBC 192, AES-192-GCM 192, AES-256-GCM 256, AES-256-CFB 256, AES-256-CFB1 256, AES-256-CFB8 256, AES-256-OFB 256, AES-256-CBC 256IPsec: IKEv1, IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES192, AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12, AES256GCM12, AES128GCM16, AES192GCM16, AES256GCM16)GRE: GRE tunnel, GRE tunnel over IPsec supportPPTP, L2TP: Client/Server instances can run simultaneously, L2TPv3, L2TP over IPsec supportStunnel: Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s codeDMVPN: Method of building scalable IPsec VPNsSSTP: SSTP client instance supportZeroTier: ZeroTier VPN client supportWireGuard: WireGuard VPN client and server supportTinc: Tinc offers encryption, authentication and compression in it's tunnels. Client and server support.Tailscale: Tailscale offers speed, stability, and simplicity over traditional VPNs. Encrypted point-to-point connections using the open source WireGuard protocolOPC UASupported modes: Client, ServerSupported connection types: TCPMODBUSSupported modes: Server, ClientSupported connection types: TCP, USBCustom registers: MODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Client functionalitySupported data formats: 8-bit: INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCIIDATA TO SERVERProtocol: HTTP(S), MQTT, Azure MQTTData to server: Extract parameters from multiple sources and different protocols, and send them all to a single serverMQTT GATEWAYModbus MQTT Gateway: Allows sending commands and receiving data from MODBUS Server through MQTT brokerDNP3Supported modes: Station, OutstationSupported connection: TCP, USBDLMSDLMS Support: DLMS - standard protocol for utility meter data exchangeSupported modes: ClientSupported connection types: TCP, USBAPITeltonika Networks Web API (beta) support: Expand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation: https://developers.teltonika-networks.comMONITORING & MANAGEMENTWEB UI: HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet statusFOTA: Firmware update from server, automatic notificationSSH: SSH (v1, v2)Email: Receive email message status alerts of various servicesTR-069: OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystemMQTT: MQTT Broker, MQTT publisherSNMP: SNMP (v1, v2, v3), SNMP TrapJSON-RPC: Management API over HTTP/HTTPSRMS: Teltonika Remote Management System (RMS)IOT PLATFORMSCloud of Things: Allows monitoring of: Device name, HW version, Serial number, FW version, WAN IP. Allows actions from the cloud: FW update, RebootCumulocity: Allows monitoring of: Device name, HW version, Serial number, FW version, WAN IP. Allows actions from the cloud: FW update, RebootAzure IoT Hub: Allows monitoring of: Wan IP, Number of bytes send/received, Model, Manufacturer, Serial, Revision, FW version and collected data of industrial devicesSYSTEM CHARACTERISTICSCPU: MediaTek, Dual-Core, 880 MHz, MIPS1004KcRAM: 256MB, DDR3FLASH storage: 16MB serial NOR flash, 256MB serial NAND flashFIRMWARE / CONFIGURATIONWEB UI: Update FW from file, check FW on server, configuration profiles, configuration backupFOTA: Update FWRMS: Update FW/configuration for multiple devices at onceKeep settings: Update FW without losing current configurationFactory settings reset: A full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configurationFIRMWARE CUSTOMISATIONOperating system: RutOS (OpenWrt based Linux OS)Supported languages: Busybox shell, Lua, C, C++Development tools: SDK package with build environment providedGPL customization: You can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients’ needsUSBData rate: USB 2.0Applications: Samba share, USB-to-serialExternal devices: Possibility to connect external HDD, flash drive, additional modem, printer, USB-serial adapterStorage formats: FAT, FAT32, exFAT, NTFS (read-only), ext2, ext3, ext4INPUT / OUTPUTInput: 1 x Digital Input, 0 - 6 V detected as logic low, 8 - 50 V detected as logic highOutput: 1 x Digital Output, Open collector output, max output 50 V, 300 mAEvents: Email, RMSI/O juggler: Allows to set certain I/O conditions to initiate eventPOWERConnector: 4-pin industrial DC power socketInput voltage range: 9 – 50 VDC, reverse polarity protection, surge protection >51 VDC 10us maxPoE (passive): Possibility to power up through LAN1 port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 50 VDCPower consumption: Idle: < 3.51 W, Max: < 8.65 WPHYSICAL INTERFACESEthernet: 4 x RJ45 ports, 10/100/1000 MbpsI/O’s: 1 x Digital Input, 1 x Digital Output on 4-pin power connectorStatus LEDs: 8 x LAN status, 1 x Power LED, 2 x 2.4G and 5G Wi-Fi LEDsPower: 1 x 4-pin power connectorAntennas: 2 x RP-SMA for Wi-FiUSB: 1 x USB A port for external devicesReset: Reboot/User default reset/Factory reset buttonOther: 1 x Grounding screwPHYSICAL SPECIFICATIONCasing material: Anodized aluminum housing and panelsDimensions (W x H x D): 115 x 32.2 x 95.2 mmWeight: 359 gMounting options: DIN rail, wall mount, flat surface (all require additional kit)OPERATING ENVIRONMENTOperating temperature: -40 °C to 75 °COperating humidity: 10% to 90% non-condensingIngress Protection Rating: IP30REGULATORY & TYPE APPROVALSRegulatory: WEEEMC EMISSIONS & IMMUNITYStandards: EN 55032:2015 + A11:2021, EN 55035:2017 + A11:2020, EN IEC 61000-3-2:2019 + A1:2021, EN 61000-3-3:2013 + A1:2019 + A2:2021, EN 301 489-1 V2.2.3, EN 301 489-3 V2.1.1, EN 301 489-17 V3.2.4, EN 301 489-52 V1.2.1ESD: EN 61000-4-2:2009Radiated Immunity: EN IEC 61000-4-3:2020EFT: EN 61000-4-4:2012Surge Immunity (AC Mains Power Port): EN 61000-4-5:2014 + A1:2017CS: EN 61000-4-6:2014DIP: EN IEC 61000-4-11:2020RFStandards:EN 301 908-1 V15.2.1EN 301 908-2 V13.1.1EN 301 908-13 V13.2.1EN 300 328 V2.2.2EN 301 893 V2.1.1EN 300 440 V2.2.1SAFETYStandards: CE: EN IEC 62368-1:2020 + A11:2020, EN IEC 62311:2020RCM: AS/NZS 62368.1:2022CB: IEC 62368-1:2018
